Acer TMP214-52 - LCD Module Removal (HDD SKU Only)

Disassembly Procedures 1-23
LCD Module Removal (HDD SKU Only) 0
Prerequisite:
Battery Pack Removal
1. Disconnect the WLAN antennas cables (A) from the WLAN module connectors
(Figure 1-29).
2. Unroute the WLAN antennas cables from the guides on the top assembly
(Figure 1-29).
3. Disconnect the eDP cable from the mainboard connector (B) (Figure 1-29).
Figure 1-29. LCD Module Removal
A
B
