Acer TravelMate 290 Series User Manual

Chapter 3 45
Disassembly Procedure Flowchart
The flowchart on the succeeding page gives you a graphic representation on the entire disassembly sequence
and instructs you on the components that need to be removed during servicing. For example, if you want to
remove the system board, you must first remove the keyboard, then disassemble the inside assembly frame in
that order.
Start
Battery
HDD Module Middle Cover
HDD Carrier Keyboard
M*2
Power Button
DIMM Cover
Memory
M*2
LCD Module
ODD Module
M*1
P*4
M*1
HDD Cover
G*4
J*2
Q*4
HDD Carrier
SUB Assy
M*2
ODD
Optical Device
Bracket
Optical Device
Holder
Optical Device
Board
M*1
Launch Board
L*1
MDC Cover
Plate
Thermal Plate
Mini PCI
Cover
P*2 P*1 K*2
MDC Card
Thermal
Module
Mini PCI
Wireless
Board
*4
CPU
Lower Case
ASSY
LED Cable
O*1
Main Board Lower Case
F*2
I*2
PCMCIA Slot
Hinge Saddles
Upper Case
Support w/
FPC
Upper Case
ASSY
N*3
O*1
Touchpad
M*5
Shielding
Speaker Set
M*2
Wireless
Antenna
P*1
K*1
M*1
M*3
P*14
P*4
G*4

Acer TravelMate 290 Series Specifications

General

Chipset	Intel 855GME
Processor	Intel Pentium M or Intel Celeron M
RAM	Up to 2GB DDR
Storage	40GB to 80GB HDD
Display	15-inch TFT
Resolution	1024 x 768 (XGA)
Graphics	Intel Extreme Graphics 2
Optical Drive	DVD-ROM
Networking	10/100 Mbps Ethernet, 56K V.92 modem
Ports	USB 2.0, VGA, Parallel, Serial
Battery	Li-ion battery
Operating System	Windows XP Professional or Windows XP Home
