Acer TravelMate B3 User Manual

16 - Your Acer notebook tour
Left view
# Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 HDMI port
Supports high-definition digital video
connections.
3 USB port Connects to USB devices.
4
USB Type-C port
with DC-in
Connects to a USB Type-C power
adapter or to USB devices with a USB
Type-C connector.
Supports DisplayPort
™
over USB-C
™
.
5
Headset/speaker
jack
Connects to audio devices (e.g.,
speakers, headphones) or a headset
with microphone.
6 Battery indicator
Indicates the computer’s battery
status.
Charging: The light shows amber
when the battery is charging.
Fully charged: The light shows blue
when in AC mode.
7
Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/1000-
based network.
1 2 3 4
5 6 7

Acer TravelMate B3 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Operating system architecture	64-bit
Processor cores	2
Processor model	N4500
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Processor manufacturer	Intel
Processor boost frequency	2.8 GHz
Display diagonal	11.6 \
Display diagonal (metric)	29.5 cm
Discrete graphics card	-
On-board graphics card model	Intel® UHD Graphics
Internal memory	4 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Optical drive type	No
Flash drive interface	PCI Express
Total storage capacity	128 GB
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery capacity	- Wh
Battery life (max)	10 h
Number of battery cells	3
AC adapter power	45 W

Weight and Dimensions

Depth	216.9 mm
Width	295 mm
Height	20.9 mm
Weight	1400 g
