Removing the Battery
1. Remove 2 screws from upper case.
Figure 3-6. Battery
Table 3-3. Battery Screw
Step
Screw
Quantity
Screw Type
Remove battery
SCREW_M2*4 mm_0.6
mm_5 mm_silver
2
2. Remove the acetate cloth from the battery.
Figure 3-7. Battery
