Machine Maintenance Procedures 1-70

Replacing the USB Board 0

1. Place the USB board (A) to its compartment on the top assembly. Make sure the

guide pins (B) and USB board screw hole are properly aligned (Figure 1-92).

Figure 1-92. Replacing the USB Board

2. Install and secure one (1) screw to the USB board (Figure 1-93).

3. Connect the USB board FFC (C) to the mainboard and USB board connectors

(Figure 1-93).

Figure 1-93. Replacing the USB Board
