Acer W510 - Keyboard Dock; Front View

26 - Your Acer tablet PC tour
Keyboard dock
The following set of images show you the optional keyboard dock.
Front view
1
2
No. Item Description
1
Pin for keyboard
dock
Secures the tablet to the dock.
2 Dock connector Connects to the dock connector on the tablet.
