ACM ACM209 User Manual

4
5. Specifications
Operating Voltage
DC 12V±10%
User Capacity
2000
Card Reading Distance
3-6 cm
Active Current
＜60mA
Idle Current
25±5 mA
Lock Output Load
Max 3A
Alarm Output Load
Max 20A
Operating Temperature
-45℃～60℃
Operating Humidity
10%- 90% RH
Waterproof
Conforms to IP68
Adjustable Door Relay time
0 -99 seconds
Adjustable Alarm Time
0- 3 minutes
Wiegand Interface
Wiegand 26 bit
Wiring Connections
Electric Lock, Exit Button, External Alarm,External reader
6. Installation
 Remove the back cover from the keypad using the supplied special screw driver
 Drill 2 holes on the wall for the Self tapping screws and I hole for the cable
 Put the supplied rubber bungs to into the two holes
 Fix the back cover firmly on the wall with 2 Self tapping screws
 Thread the cable through the cable hole
 Attach the keypad to the back cover.
