6.3 DMX512 Configuration
Please refer to below configurations to control the fixtures
Attentions:
1. The unit will maintain the last condition until reset if you cut-off the DMX signal.
2. For the channel Function, keep the value for about 3 seconds, then the corresponding function
will take into effect.
34 Channels (Mode 1):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0°

540°
2 000-255 PAN FINE
3
000-255
TILT
0°270°
4 000-255 TILT FINE
5
000-255
PAN/TILT SPEED
Fast to Slow
6
000-255
CYAN
0%

100%
7
000-255
MAGENTA
0%

100%
8
000-255
YELLOW
0%

100%
9
000-255
CTO
0%

100%
10
000-009
010-018
019-027
028-036
037-045
046-063
064-127
128-189
190-193
194-255
COLOR
Open
Color 1
Color 2
Color 3
Color 4
Color 5
Color Wheel Indexing
Counter-Clockwise Rotation, Fast to Slow
Stop
Clockwise Rotation, Slow to Fast
11
000-007
008-015
016-023
024-031
GOBO 1
Open
Gobo 1
Gobo 2
Gobo 3
