ACME Oxygen - Address Setting; DMX512 Configuration

- 30 -
6.2 Address Setting
If you use a universal DMX controller to control the units, you have to set DMX address
between 1 and 512 so that the units can receive DMX signal.
Press the MENU button to access the control menus, select DMX Settings, press the ENTER
button to confirm. Use the UP/DOWN button to select DMX Address, press the ENTER
button to confirm, the present address will show on the display. Use the UP/DOWN button
to adjust the address between 001 and 512, press the ENTER button to store. To exit the
menu, press MENU, or wait 30 seconds.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel Mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
17 channels
1
18
35
52
37 channels
1
38
75
112
6.3 DMX512 Configuration
Please control the fixture by referring to the configurations below.
17 Channels (Mode 1):
CHANNEL
VALUE
FUNCTION
1
000-255
PAN
0°540°
2
000-255
PAN FINE
3
000-255
TILT
0°230°
4
000-255
TILT FINE
5
000-255
ZOOM
WideNarrow
Attentions:
 The unit will maintain the last condition until reset if you cut-off the DMX signal.
 For the channel Function, keep the value for about 3 seconds, then the
corresponding function will take into effect.
