Acorp 6BX83 - System Memory (DIMM Modules)

12 / Chapter 3 Installation
System Memory ( DIMM Module)
This 6BX83 main board supports four 168 pins DIMM of 16 MB,
32 MB, 64 MB, 128 MB ,256MB to form a memory size between
16MB to 256MB.
The DRAM can be either 45ns,50ns,or 60ns 3.3v SDRAM,and 3.3v
Enhanced Data Output (EDO) RAM.
Install memory in any or all Banks in Combination:
Bank Memory module
DIMM 1 16MB,32MB,64MB,128MB,256MB
( Bank 0-1 ) 168 pin,3.3v SDRAM / EDO RAM
DIMM 2 16MB,32MB,64MB,128MB,256MB
( Bank 2-3 ) 168 pin 3.3v,SDRAM / EDO RAM
DIMM 3 16MB,32MB,64MB,128MB,256MB
( Bank 4-5 ) 168 pin 3.3v,SDRAM / EDO RAM
DIMM 4 16MB,32MB,64MB,128MB,256MB
( Bank 6-7 ) 168 pin 3.3v,SDRAM / EDO RAM
Total System Memory(Max 1024MB)
Note :


 The DIMM Slot does not support any 5v EDO DIMM
module.


 The DIMM Slot does not support any 5v SDRAM DIMM
module.


 Memory speed setup is required through "Auto Con-
figuration" in BIOS chipset Setup of BIOS
SOFTWARE. If several speed memories are used, You
must set Auto Configuration to low. Example If both
50ns, 60ns are used, Please set Auto configuration to
60ns.


 It's allowed any DIMM module put in any DIMM slot.
It's allowed there are different capacity DIMM module
in all DIMM slot.
