18
Disassembly
Inner Door/Window Removal
1. Open oven door.
2. Remove screws on hinge side.
3. Beginning at the bottom, carefully insert 1”(25 mm) putty knifebetween inner and outer door. Pry up on inner door
to release tabs, (2 tabs per side). Work in a clockwise direction to release all tabs, see illustration below.
1
2
3
4
Tabs
Remove T15
safety Torx screws
CAUTION
!
When glass retainer is removed, be careful glass
does not fall out of frame.
To Next Page
