ACPro AUHD18ND3F1O - Page 6

Ƶ
• For the units: 36~48K
Unit: mm (inches)
Model A B C D E F G H I J
AFH18D3F3I
1100
(43-3/8)
515
(20-3/8)
820
(32-1/4)
1160
(45-5/8)
1280
(50-
3/8)
560
(22)
1000
(39-1/2)
160
(6-1/4)
235
(9-1/4)
270
(10-1/2)
AFH24D3F3I
1010
(39-3/4)
750
(29-1/2)
820
(32-1/4)
1115
(43-7/8)
1225
(48-1/4)
775
(30-1/2)
980
(38-5/8)
160
(6-1/4)
230
(9)
290
(11-3/8)
AFH30D3F3I
AFH36D3F3I
1175
(46-1/4)
645
(25-3/8)
850
(33-1/2)
1150
(45-1/4)
1340
(85-1/4)
750
(29-1/2)
980
(38-5/8)
19
(38-5/8)
230
(9)
350
(13-3/4)
AFH42D3F3I
AFH48D3F3I
