ACR Electronics PLB-350C - Anatomy of your beacon

Y1-03-0244E 8
4. Anatomy of your beacon
NOTE: The appearance of your beacon may vary from this picture.
Figure 1
Antenna
Latch
Antenna
latch
Digital display
FRONT BACK
GPS
antenna
location
Antenna:
Wrapped
around
beacon
UIN Label: Applied at
the factory, the 15
character hexadecimal
number is unique to
each beacon.
Activation
button cover
Battery expiration label
with the month/ year
the battery needs to be
replaced.
Keypad
Multi-language label:
This optional label may
be applied for ease of
use.
Registration decal
supplied by some
countries: Once the
beacon is registered,
the label goes here.
