Y1-03-0250 Rev. C 9
GPS Interface
Stowage Port
Category 2 – QuickDraw™ Bracket
Category 1 – SeaShelter™
3
Bracket
Spring
Release
Knob
HydroFix™
Hydrostatic
Release Unit
(HRU)
Ejector
Spring
Antenna
Hook
Front cover
hook (detent)
Optional GPS
Interface
Cable
Antenna Hook
Water Sensor
Deactivation Magnet
Release Latch
