Acrel ADL3000-E - Page 17

14
004FH
Start of period 6: minute
Start of period 6: hour
2
R/W
0050H
Rate no. of period 7
Start of period 7: minute
2
R/W
0051H
Start of period 7: hour
Rate no. of period 8
2
R/W
0052H
Start of period 8: minute
Start of period 8: hour
2
R/W
0053H
Rate no. of period 1
Start of period 1: minute
2
R/W
The second time list
Rate No.:
1: sharp
2: peak
3: flat
4: Valley
0: no rate
0054H
Start of period 1: hour
Rate no. of period 2
2
R/W
0055H
Start of period 2: minute
Start of period 2: hour
2
R/W
0056H
Rate no. of period 3
Start of period 3: minute
2
R/W
0057H
Start of period 3: hour
Rate no. of period 4
2
R/W
0058H
Start of period 4: minute
Start of period 4: hour
2
R/W
0059H
Rate no. of period 5
Start of period 5: minute
2
R/W
005AH
Start of period 5: hour
Rate no. of period 6
2
R/W
005BH
Start of period 6: minute
Start of period 6: hour
2
R/W
005CH
Rate no. of period 7
Start of period 7: minute
2
R/W
005DH
Start of period 7: hour
Rate no. of period 8
2
R/W
005EH
Start of period 8: minute
Start of period 8: hour
2
R/W
005FH
Rate no. of period 9
Start of period 9: minute
2
R/W
0060H
Start of period 9: hour
2
R/W
0061H
Voltage of A phase
2
R
U=data*PT*0.1
Unit:V
0062H
Voltage of B phase
2
R
0063H
Voltage of C phase
2
R
