Acrel ADL3000-E - History Energy Frozen Time and History Energy Energy Date; SOE Record

21
0251H
Minimum current on C phase and
occur time
6
R
0254H
Minimum active power on A phase
and occur time
8
R
0258H
Minimum active power on B phase
and occur time
8
R
025CH
Minimum active power on C phase
and occur time
8
R
0260H
Minimum active power and occur
time
8
R
0264H
Minimum reactive power on A phase
and occur time
8
R
0268H
Minimum reactive power on B
phase and occur time
8
R
026CH
Minimum reactive power on C
phase and occur time
8
R
0270H
Minimum reactive power and occur
time
8
R
0274H
Minimum apparent power on A
phase and occur time
8
R
0278H
Minimum apparent power on B
phase and occur time
8
R
027EH
Minimum apparent power on C
phase and occur time
8
R
0280H
Minimum apparent power and occur
time
8
R
0285H-
1FFFH
Reserve
2000H
T1 temperature
2
R
2001H
T2 temperature
2
R
2002H
T3 temperature
2
R
9.2 History energy frozen time and history energy energy date
ADL3000-EF’s registers on frozen by day and by month.
Address
Name
R/W
Note
0121H
Frozen time by day
R/W
Null (High byte) Hour(Low byte)
0122H
Frozen time by month
R/W
Day(High byte) Hour(Low byte)
ADL3000-EF can achieve the history energy statistic in last 48 months and last 90days. (Each
tariff rate of energy can be recorded.)The history energy record can only be read by assemblage
and the length of whole part is 120 byte (60 registers), and list below is the registers’ name:
Address
Name
Data list
Name
