Acrel DTSD1352 User Manual

27
0035H
发生时间：日、月
Occur time : DD-MM
0036H
正向无功最大需量
Maximum forward reactive
demand
0037H
发生时间：分、时
Occur time: mm-hh
0038H
发生时间：日、月
Occur time : DD-MM
0039H
反向无功最大需量
Maximum reversing reactive
demand
003AH
发生时间：分、时
Occur time: mm-hh
003BH
发生时间：日、月
Occur time : DD-MM
9.3 分次谐波数据 Harmonic data
DTSD1352 可选配谐波测量，统计分相 31 次谐波电压电流、总谐波畸变率、分相谐波
电压电流、分相谐波有功功率无功功率、分相基波电流电压、分相基波有功功率无功功率。
DTSD1352 has function of harmonic. The function include 31
st
harmonic statistics of voltage
and current, harmonic voltage and current of each phase apparently, harmonic active/reactive
power of each phase apparently, fundamental voltage and current of each phase apparently and
fundamental active/reactive power of each phase apparently.
地址
Addr
名称 Name
长度
Length
R/W
备注 Note
05DDH
THDUa
2
R
分相电压电流总畸变
率
Total distortion rate of
voltage and current on
each phase
整形,保留 2 位小数
Int
Keep 3 decimal places
05DEH
THDUb
2
R
05DFH
THDUc
2
R
05E0H
THDIa
2
R
05E1H
THDIb
2
R
05E2H
THDIc
2
R
05E3H
THUa
2×30
电压分相 2~31 次谐
波含量
Harmonic voltage on
2
nd
-31
st
整形,保留 2 位小数
Int
Keep 3 decimal places
0601H
THUb
2×30
061FH
THUc
2×30
063DH
THIa
2×30
电流分相 2~31 次谐
波含量
Harmonic current on
065BH
THIb
2×30
0679H
THIc
2×30
