5.3.10 Close door and fasten the draw latch.
5.3.11 Reconnect the power supply cord, then turn the unit on, and check the pressure
gauge at the control panel. If pressure still exceeds the pressure stated above,
consult your distributor.
5.4 Used filter disposal:
5.4.1 Used filters are considered contaminated waste and are to be disposed in
compliance with all applicable regulations. Personnel replacing filters must wear
personal protective equipment and follow safe work practices as per applicable
regulations.
6. REPLACEMENT PARTS LIST:
Item: Part Number: Descriptions:
1 76012802 Blower Motor 1.75 HP
2 76252002 Blower for FA2000
3 38900423 FA2000 Motor & Blower Assembly
4 72650102 Capacitor 35uF, 370VAC, 50/60Hz
5 Call Dist. HEPA Filter 24” x 24” x 11.5”
6 Call Dist. Ring Panel Filter 24” x 24” x 1”
7 Call Dist. Pre-filter Pad 24” x 24” x 1”
8 32000106 FA2000 HEPA Clip Kit
9 32000037 FA2000 Control Panel Plate Blk
10 66020101 Gauge - Pressure Minihelic
11 72150202 Breaker - 20 Amp Push Button
12 72270304 Switch – SPDT 3 Prong
13 72250301 PS Receptacle – Recessed Male 15 Amp
14 74100101 Link lock (Draw Latch) – No Spring
15 74100201 Link lock - Keeper Plate
16 74500104 Caster 4” Swivel
17 74500204 Caster 4” with brake
18 74090520 Grab Handle with w/ Spring Blk
19 71200204 Terminal, Push On 16-14 Female clear
20 32000023 FA2000 Alum.Control Box
