SPLIT SYSTEMS
Technical Manual
AIR CONDITIONER
DUCTED BLOWER
H SERIES
Cooling only [50Hz]
A5DB-H series
TM-5SB-H-AM-A4
R410A

Table of Contents

Questions and Answers

  • K
    kristawilliamsAug 4, 2025
    Why is the airflow too slow in my Acson international Air Conditioner, or why isn't the room cooling sufficiently?
    • M
      Miss Theresa BlevinsAug 4, 2025
      If the airflow from your Acson international Air Conditioner is too slow, or the room isn't cooling enough, several factors could be at play: * The air filter might be dirty, in which case you should clean it. * Open doors and windows can affect cooling efficiency, so close them. * The air suction and discharge of the unit may be clogged; clear any blockages. * The temperature setting might be too high; try setting it lower.
  • P
    philip40Aug 10, 2025
    Why does the compressor in my Acson international H Series operate continuously?
    • A
      Andrew SchroederAug 10, 2025
      Your Acson international Air Conditioner's compressor might run continuously due to several reasons. If the air filter is dirty, clean it. Also, check the temperature settings: if it's too low for cooling, use a higher setting; if it's too high for heating, use a lower setting.
  • D
    Dr. Carrie GallowayAug 15, 2025
    What to do if there's condensation on the front air grille of my Acson international Air Conditioner?
    • C
      Chelsea BakerAug 15, 2025
      Condensation on the front air grille of your Acson international Air Conditioner indoor unit can occur due to air humidity after extended operation or if the set temperature is too low. To address this, increase the temperature setting and operate the unit at a high fan speed.
  • D
    dennisfoxAug 21, 2025
    Why doesn't the compressor operate 3 minutes after starting my Acson international Air Conditioner?
    • K
      Katelyn ArellanoAug 21, 2025
      If the compressor of your Acson international Air Conditioner doesn't start immediately after turning on the unit, it might be due to a protection mechanism that prevents frequent starts. Wait for 3 to 4 minutes; the compressor should start operating by itself.
  • P
    Paul BurnsAug 27, 2025
    How to resume Acson international H Series unit after a power failure?
    • D
      Diana FordAug 28, 2025
      To restart your Acson international Air Conditioner after a power failure, turn on the unit using the wireless or wired controller.

Summary

APPLICATION INFORMATION

Refrigerant Circuit Diagram

Illustrates the refrigerant flow path for cooling operation.

Installation Guideline

Provides instructions for unit installation, including site survey and electrical connection.

SELECTION PROCESS

Fan Performance Chart

PERFORMANCE DATA

Calculation Steps

Performance Tables

Contains detailed performance data tables (TC, SC, PI) for various operating conditions.

WIRING DIAGRAMS

SERVICING & MAINTENANCE

MAINTENANCE

TROUBLESHOOTING

Phase Sequencer

Explains the phase protection system and its LED indicators for fault diagnosis.
