Acson A4LC 40 C User Manual

26
MODEL : A4LC 30/40/50C
1. ASSY. BASE PAN 10. BACK RIGHT PANEL
2. SUCTION VALVE 11. TOP PANEL
3. LIQUID VALVE 12. CONDENSER COIL ASSY.
4. PARTITION PANEL 13. MOTOR BRACKET
5. CRANKCASE HEATER 14. SIDE LEFT PANEL
6. COMPRESSOR ASSY. 15. FAN MOTOR ASSY.
7. SERVICE PANEL 16. FAN BLADE
8. TERMINAL BOARD MAIN ASSY. 17. FRONT PANEL ASSY.
9. ACCUMULATOR
