Acson A4LC 40 C User Manual

27
MODEL : A4LC 30/40/50CR
1. ASSY. BASE PAN 11. 4 WAY VALVE ASSY.
2. SUCTION VALVE 12. BACK RIGHT PANEL
3. LIQUID VALVE 13. DEFROST SENSOR AND CLIP
4. PARTITION PANEL 14. TOP PANEL
5. CRANKCASE HEATER 15. CONDENSER COIL ASSY.
6. COMPRESSOR ASSY. 16. MOTOR BRACKET
7. TXV ASSY. 17. SIDE LEFT PANEL
8. SERVICE PANEL 18. FAN MOTOR ASSY.
9. TERMINAL BOARD MAIN ASSY. 19. FAN BLADE
10. ACCUMULATOR 20. FRONT PANEL ASSY.
