R410A MODELS
(COOLING ONLY)
MODEL : A5CM 15E / A5LC 15C
MODEL : A5CM 20E / A5LC 20C (1 PHASE)
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
4.362 2.573 3.980 2.190 3.593 1.802 3.206 1.414 2.819 1.027 2.354 0.562
16
4.440 2.359 4.074 2.005 3.706 1.648 3.338 1.292 2.970 0.936 2.528 0.508
16
4.440 3.385 4.074 3.031 3.706 2.675 3.338 2.318 2.970 1.962 2.528 1.534
17
4.517 3.171 4.168 2.846 3.819 2.521 3.470 2.196 3.121 1.871 2.702 1.481
18
4.597 2.960 4.266 2.665 3.935 2.370 3.604 2.075 3.273 1.781 2.876 1.427
19
4.679 2.753 4.380 2.515 4.082 2.276 3.783 2.038 3.450 1.736 3.050 1.373
20
4.752 2.529 4.437 2.257 4.122 1.986 3.807 1.714 3.492 1.443 3.114 1.117
18
4.597 3.986 4.266 3.691 3.935 3.396 3.604 3.102 3.273 2.807 2.876 2.453
19
4.679 3.779 4.380 3.541 4.082 3.302 3.783 3.064 3.450 2.762 3.050 2.400
20
4.752 3.555 4.437 3.283 4.122 3.012 3.807 2.740 3.492 2.469 3.114 2.143
21
4.827 3.336 4.510 3.057 4.193 2.778 3.876 2.500 3.559 2.221 3.178 1.887
22
4.903 3.116 4.583 2.831 4.264 2.545 3.945 2.259 3.625 1.974 3.242 1.631
23
4.978 2.897 4.657 2.604 4.335 2.312 4.014 2.019 3.692 1.726 3.306 1.374
24
5.054 2.678 4.730 2.378 4.406 2.078 4.082 1.778 3.759 1.478 3.370 1.118
20
4.752 4.068 4.437 3.796 4.122 3.525 3.807 3.254 3.492 2.982 3.114 2.656
21
4.827 3.849 4.510 3.570 4.193 3.292 3.876 3.013 3.559 2.734 3.178 2.400
22
4.903 3.630 4.583 3.344 4.264 3.058 3.945 2.772 3.625 2.487 3.242 2.144
23
4.978 3.410 4.657 3.117 4.335 2.825 4.014 2.532 3.692 2.239 3.306 1.887
24
5.054 3.191 4.730 2.891 4.406 2.591 4.082 2.291 3.759 1.991 3.370 1.631
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.715 3.788 5.176 3.247 4.622 2.692 4.068 2.137 3.514 1.581 2.849 0.915
16
5.842 3.492 5.34 2.99 4.83 2.481 4.32 1.971 3.811 1.462 3.199 0.85
16
5.842 4.601 5.34 4.099 4.83 3.59 4.32 3.08 3.811 2.57 3.199 1.959
17
5.968 4.306 5.503 3.842 5.038 3.378 4.573 2.914 4.107 2.451 3.549 1.894
18
6.102 4.017 5.678 3.596 5.255 3.176 4.831 2.755 4.408 2.334 3.899 1.829
19
6.238 3.737 5.868 3.403 5.498 3.068 5.128 2.733 4.729 2.293 4.249 1.764
20
6.36 3.431 5.971 3.051 5.582 2.671 5.194 2.29 4.805 1.91 4.339 1.454
18
6.102 5.126 5.678 4.705 5.255 4.285 4.831 3.864 4.408 3.443 3.899 2.938
19
6.238 4.846 5.868 4.512 5.498 4.177 5.128 3.842 4.729 3.402 4.249 2.873
20
6.36 4.54 5.971 4.16 5.582 3.78 5.194 3.399 4.805 3.019 4.339 2.563
21
6.484 4.243 6.088 3.86 5.693 3.477 5.298 3.094 4.902 2.712 4.428 2.252
22
6.608 3.945 6.206 3.56 5.804 3.175 5.402 2.789 4.999 2.404 4.517 1.942
23
6.732 3.648 6.323 3.26 5.914 2.872 5.505 2.484 5.097 2.097 4.606 1.631
24
6.856 3.35 6.44 2.96 6.025 2.57 5.609 2.18 5.194 1.789 4.695 1.321
20
6.36 5.095 5.971 4.714 5.582 4.334 5.194 3.954 4.805 3.574 4.339 3.117
21
6.484 4.797 6.088 4.414 5.693 4.032 5.298 3.649 4.902 3.266 4.428 2.807
22
6.608 4.5 6.206 4.115 5.804 3.729 5.402 3.344 4.999 2.959 4.517 2.496
23
6.732 4.202 6.323 3.815 5.914 3.427 5.505 3.039 5.097 2.651 4.606 2.186
24
6.856 3.905 6.44 3.515 6.025 3.124 5.609 2.734 5.194 2.344 4.695 1.875
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
