R22 MODELS
(HEATPUMP)
MODEL : ACM 15ER / ALC 15CR
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
4.198 2.455 3.897 2.140 3.596 1.825 3.295 1.510 2.995 1.195 2.634 0.816
16
4.255 2.390 3.958 2.065 3.660 1.741 3.363 1.417 3.066 1.093 2.709 0.704
16
4.255 3.353 3.958 3.029 3.660 2.705 3.363 2.381 3.066 2.056 2.709 1.667
17
4.313 3.288 4.019 2.955 3.725 2.621 3.431 2.288 3.137 1.954 2.784 1.554
18
4.370 3.224 4.080 2.881 3.789 2.538 3.498 2.195 3.208 1.853 2.859 1.441
19
4.428 3.159 4.140 2.807 3.853 2.455 3.566 2.103 3.279 1.751 2.934 1.328
20
4.486 3.095 4.207 2.744 3.928 2.393 3.649 2.042 3.370 1.691 3.036 1.270
18
4.370 4.187 4.080 3.844 3.789 3.502 3.498 3.159 3.208 2.816 2.859 2.405
19
4.428 4.122 4.140 3.770 3.853 3.418 3.566 3.066 3.279 2.714 2.934 2.292
20
4.486 4.059 4.207 3.708 3.928 3.357 3.649 3.006 3.370 2.655 3.036 2.234
21
4.544 3.996 4.277 3.653 4.010 3.310 3.742 2.967 3.475 2.624 3.154 2.213
22
4.603 3.933 4.347 3.598 4.091 3.263 3.836 2.928 3.580 2.593 3.273 2.192
23
4.661 3.870 4.417 3.543 4.173 3.216 3.929 2.890 3.685 2.563 3.392 2.170
24
4.720 3.807 4.487 3.489 4.255 3.170 4.022 2.851 3.790 2.532 3.511 2.149
20
4.540 4.540 4.207 4.190 3.928 3.839 3.649 3.488 3.370 3.137 3.036 2.716
21
4.544 4.478 4.277 4.135 4.010 3.792 3.742 3.449 3.475 3.106 3.154 2.695
22
4.603 4.415 4.347 4.080 4.091 3.745 3.836 3.410 3.580 3.075 3.273 2.673
23
4.661 4.352 4.417 4.025 4.173 3.698 3.929 3.371 3.685 3.044 3.392 2.652
24
4.720 4.289 4.487 3.970 4.255 3.651 4.022 3.333 3.790 3.014 3.511 2.631
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
1.760 1.760 2.115 2.115 2.233 2.233 3.532 3.532 4.241 4.241 4.596 4.596 4.950 4.950
17 1.738 1.738 2.079 2.079 2.192 2.192 3.471 3.471 4.127 4.127 4.468 4.468 4.809 4.809
19
1.716 1.716 2.043 2.043 2.152 2.152 3.410 3.410 4.012 4.012 4.340 4.340 4.669 4.669
21 1.693 1.693 2.007 2.007 2.111 2.111 3.350 3.350 3.897 3.897 4.213 4.213 4.528 4.528
23 1.669 1.669 1.970 1.970 2.071 2.071 3.232 3.232 3.783 3.783 4.085 4.085 4.387 4.387
25
1.645 1.645 1.934 1.934 2.030 2.030 3.115 3.115 3.668 3.668 3.957 3.957 4.246 4.246
27 1.621 1.621 1.897 1.897 1.989 1.989 2.997 2.997 3.554 3.554 3.830 3.830 4.106 4.106
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
