Acson ACM 15 E User Manual

71
R22 MODELS
(HEATPUMP)
MODEL : ACM 20ER / ALC 18CR
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.743 3.699 5.397 3.404 5.050 3.110 4.703 2.816 4.356 2.522 3.940 2.168
16
5.969 3.449 5.599 3.179 5.228 2.910 4.858 2.640 4.488 2.371 4.044 2.047
16
5.969 4.359 5.599 4.090 5.228 3.820 4.858 3.551 4.488 3.281 4.044 2.958
17
6.194 4.109 5.800 3.864 5.407 3.620 5.014 3.375 4.621 3.130 4.149 2.837
18
6.419 3.859 6.002 3.639 5.586 3.419 5.169 3.199 4.753 2.979 4.253 2.715
19
6.644 3.609 6.204 3.414 5.765 3.219 5.325 3.023 4.885 2.828 4.358 2.594
20
6.870 3.358 6.417 3.183 5.963 3.008 5.510 2.833 5.056 2.658 4.512 2.448
18
6.419 4.770 6.002 4.550 5.586 4.330 5.169 4.110 4.753 3.890 4.253 3.626
19
6.644 4.520 6.204 4.324 5.765 4.129 5.325 3.934 4.885 3.739 4.358 3.505
20
6.870 4.269 6.417 4.094 5.963 3.919 5.510 3.744 5.056 3.569 4.512 3.359
21
7.097 4.018 6.636 3.860 6.175 3.702 5.714 3.544 5.253 3.386 4.700 3.196
22
7.324 3.767 6.855 3.626 6.387 3.485 5.918 3.344 5.450 3.202 4.888 3.033
23
7.551 3.516 7.075 3.392 6.599 3.268 6.123 3.143 5.647 3.019 5.075 2.871
24
7.778 3.265 7.294 3.158 6.811 3.050 6.327 2.943 5.844 2.836 5.263 2.708
20
6.870 4.724 6.417 4.549 5.963 4.374 5.510 4.199 5.056 4.024 4.512 3.814
21
7.097 4.473 6.636 4.315 6.175 4.157 5.714 3.999 5.253 3.841 4.700 3.651
22
7.324 4.222 6.855 4.081 6.387 3.940 5.918 3.799 5.450 3.658 4.888 3.489
23
7.551 3.971 7.075 3.847 6.599 3.723 6.123 3.599 5.647 3.475 5.075 3.326
24
7.778 3.720 7.294 3.613 6.811 3.506 6.327 3.399 5.844 3.292 5.263 3.163
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
2.597 2.597 3.151 3.151 3.335 3.335 5.366 5.366 6.474 6.474 7.028 7.028 7.582 7.582
17
2.556 2.556 3.094 3.094 3.274 3.274 5.299 5.299 6.299 6.299 6.833 6.833 7.367 7.367
19
2.516 2.516 3.038 3.038 3.213 3.213 5.231 5.231 6.124 6.124 6.637 6.637 7.151 7.151
21 2.475 2.475 2.982 2.982 3.151 3.151 5.164 5.164 5.948 5.948 6.442 6.442 6.935 6.935
23 2.447 2.447 2.929 2.929 3.090 3.090 4.958 4.958 5.773 5.773 6.246 6.246 6.720 6.720
25 2.419 2.419 2.876 2.876 3.028 3.028 4.751 4.751 5.597 5.597 6.051 6.051 6.504 6.504
27
2.390 2.390 2.823 2.823 2.967 2.967 4.545 4.545 5.422 5.422 5.855 5.855 6.289 6.289
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
