R22 MODELS
(HEATPUMP)
MODEL : ACM 20ER / ALC 20CR
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.850 3.645 5.531 3.384 5.213 3.123 4.894 2.862 4.575 2.602 4.193 2.288
16
6.081 3.339 5.746 3.114 5.410 2.889 5.074 2.664 4.738 2.439 4.335 2.169
16
6.081 4.310 5.746 4.085 5.410 3.860 5.074 3.635 4.738 3.410 4.335 3.140
17
6.313 4.004 5.960 3.814 5.607 3.625 5.254 3.436 4.900 3.247 4.477 3.020
18
6.544 3.697 6.174 3.544 5.804 3.391 5.433 3.238 5.063 3.085 4.619 2.901
19
6.776 3.391 6.388 3.274 6.001 3.157 5.613 3.039 5.226 2.922 4.761 2.781
20
7.008 3.084 6.605 2.993 6.202 2.902 5.800 2.811 5.397 2.720 4.914 2.610
18
6.544 4.668 6.174 4.515 5.804 4.362 5.433 4.209 5.063 4.055 4.619 3.872
19
6.776 4.362 6.388 4.245 6.001 4.127 5.613 4.010 5.226 3.893 4.761 3.752
20
7.008 4.054 6.605 3.963 6.202 3.872 5.800 3.781 5.397 3.690 4.914 3.581
21
7.240 3.746 6.823 3.675 6.407 3.604 5.990 3.532 5.574 3.461 5.074 3.376
22
7.472 3.438 7.041 3.386 6.611 3.335 6.181 3.284 5.750 3.232 5.234 3.170
23
7.703 3.130 7.259 3.098 6.815 3.066 6.371 3.035 5.927 3.003 5.394 2.965
24
7.935 2.822 7.477 2.810 7.020 2.798 6.562 2.786 6.104 2.774 5.554 2.759
20
7.008 4.540 6.605 4.449 6.202 4.358 5.800 4.267 5.397 4.176 4.914 4.067
21
7.240 4.232 6.823 4.160 6.407 4.089 5.990 4.018 5.574 3.947 5.074 3.861
22
7.472 3.923 7.041 3.872 6.611 3.820 6.181 3.769 5.750 3.717 5.234 3.656
23
7.703 3.615 7.259 3.583 6.815 3.552 6.371 3.520 5.927 3.488 5.394 3.450
24
7.935 3.307 7.477 3.295 7.020 3.283 6.562 3.271 6.104 3.259 5.554 3.245
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
2.506 2.506 3.124 3.124 3.330 3.330 5.597 5.597 6.834 6.834 7.452 7.452 8.071 8.071
17
2.446 2.446 3.062 3.062 3.267 3.267 5.499 5.499 6.648 6.648 7.245 7.245 7.841 7.841
19
2.386 2.386 2.999 2.999 3.204 3.204 5.401 5.401 6.462 6.462 7.037 7.037 7.612 7.612
21
2.326 2.326 2.937 2.937 3.140 3.140 5.303 5.303 6.276 6.276 6.829 6.829 7.382 7.382
23
2.319 2.319 2.887 2.887 3.077 3.077 5.113 5.113 6.089 6.089 6.621 6.621 7.153 7.153
25
2.311 2.311 2.838 2.838 3.014 3.014 4.924 4.924 5.903 5.903 6.413 6.413 6.923 6.923
27
2.304 2.304 2.789 2.789 2.951 2.951 4.734 4.734 5.717 5.717 6.205 6.205 6.694 6.694
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
