Acson ACM 15 E - Page 82

80
R410A MODELS
(HEATPUMP)
MODEL : A5CM 15ER / A5LC 15CR
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
4.362 2.573 3.980 2.190 3.593 1.802 3.206 1.414 2.819 1.027 2.354 0.562
16
4.440 2.359 4.074 2.005 3.706 1.648 3.338 1.292 2.970 0.936 2.528 0.508
16
4.440 3.385 4.074 3.031 3.706 2.675 3.338 2.318 2.970 1.962 2.528 1.534
17
4.517 3.171 4.168 2.846 3.819 2.521 3.470 2.196 3.121 1.871 2.702 1.481
18
4.597 2.960 4.266 2.665 3.935 2.370 3.604 2.075 3.273 1.781 2.876 1.427
19
4.679 2.753 4.380 2.515 4.082 2.276 3.783 2.038 3.450 1.736 3.050 1.373
20
4.752 2.529 4.437 2.257 4.122 1.986 3.807 1.714 3.492 1.443 3.114 1.117
18
4.597 3.986 4.266 3.691 3.935 3.396 3.604 3.102 3.273 2.807 2.876 2.453
19
4.679 3.779 4.380 3.541 4.082 3.302 3.783 3.064 3.450 2.762 3.050 2.400
20
4.752 3.555 4.437 3.283 4.122 3.012 3.807 2.740 3.492 2.469 3.114 2.143
21
4.827 3.336 4.510 3.057 4.193 2.778 3.876 2.500 3.559 2.221 3.178 1.887
22
4.903 3.116 4.583 2.831 4.264 2.545 3.945 2.259 3.625 1.974 3.242 1.631
23
4.978 2.897 4.657 2.604 4.335 2.312 4.014 2.019 3.692 1.726 3.306 1.374
24
5.054 2.678 4.730 2.378 4.406 2.078 4.082 1.778 3.759 1.478 3.370 1.118
20
4.752 4.068 4.437 3.796 4.122 3.525 3.807 3.254 3.492 2.982 3.114 2.656
21
4.827 3.849 4.510 3.570 4.193 3.292 3.876 3.013 3.559 2.734 3.178 2.400
22
4.903 3.630 4.583 3.344 4.264 3.058 3.945 2.772 3.625 2.487 3.242 2.144
23
4.978 3.410 4.657 3.117 4.335 2.825 4.014 2.532 3.692 2.239 3.306 1.887
24
5.054 3.191 4.730 2.891 4.406 2.591 4.082 2.291 3.759 1.991 3.370 1.631
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
2.091 2.091 2.366 2.366 2.458 2.458 3.469 3.469 4.020 4.020 4.296 4.296 4.571 4.571
17
2.036 2.036 2.334 2.334 2.405 2.405 3.465 3.465 3.974 3.974 4.251 4.251 4.527 4.527
19
1.981 1.981 2.302 2.302 2.352 2.352 3.460 3.460 3.927 3.927 4.205 4.205 4.484 4.484
21 1.926 1.926 2.252 2.252 2.299 2.299 3.418 3.418 3.881 3.881 4.160 4.160 4.440 4.440
23 1.871 1.871 2.183 2.183 2.245 2.245 3.338 3.338 3.835 3.835 4.115 4.115 4.396 4.396
25 1.817 1.817 2.114 2.114 2.192 2.192 3.257 3.257 3.789 3.789 4.070 4.070 4.352 4.352
27
1.762 1.762 2.045 2.045 2.139 2.139 3.177 3.177 3.742 3.742 4.025 4.025 4.308 4.308
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
