Acson ACM 15 E User Manual

84
R410A MODELS
(HEATPUMP)
MODEL : A5CM 25ER / A5LC 25CR (3 PHASE)
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
6.763 4.405 6.436 4.061 6.057 3.765 5.677 3.469 5.298 3.173 4.842 2.818
16
6.992 4.182 6.649 3.879 6.279 3.600 5.910 3.321 5.540 3.042 5.097 2.708
16
6.992 5.341 6.649 5.038 6.279 4.759 5.910 4.480 5.540 4.201 5.097 3.867
17
7.221 5.117 6.861 4.855 6.502 4.594 6.142 4.332 5.783 4.071 5.351 3.757
18
7.474 4.871 7.115 4.635 6.755 4.400 6.396 4.164 6.037 3.929 5.606 3.646
19
7.730 4.623 7.386 4.406 7.042 4.188 6.699 3.971 6.318 3.773 5.860 3.536
20
7.975 4.363 7.592 4.103 7.209 3.842 6.826 3.582 6.443 3.322 5.984 3.009
18
7.474 6.030 7.115 5.794 6.755 5.559 6.396 5.323 6.037 5.088 5.606 4.805
19
7.730 5.782 7.386 5.565 7.042 5.347 6.699 5.130 6.318 4.932 5.860 4.695
20
7.975 5.522 7.592 5.262 7.209 5.001 6.826 4.741 6.443 4.481 5.984 4.168
21
8.223 5.260 7.816 4.949 7.409 4.638 7.002 4.326 6.595 4.015 6.107 3.641
22
8.471 4.999 8.040 4.636 7.609 4.274 7.178 3.912 6.747 3.549 6.230 3.115
23
8.719 4.737 8.264 4.324 7.809 3.910 7.354 3.497 6.899 3.084 6.353 2.588
24
8.967 4.476 8.488 4.011 8.009 3.547 7.530 3.082 7.051 2.618 6.476 2.061
20
7.975 6.101 7.592 5.841 7.209 5.581 6.826 5.321 6.443 5.060 5.984 4.748
21
8.223 5.840 7.816 5.529 7.409 5.217 7.002 4.906 6.595 4.595 6.107 4.221
22
8.471 5.578 8.040 5.216 7.609 4.854 7.178 4.491 6.747 4.129 6.230 3.694
23
8.719 5.317 8.264 4.903 7.809 4.490 7.354 4.077 6.899 3.663 6.353 3.167
24
8.967 5.055 8.488 4.591 8.009 4.126 7.530 3.662 7.051 3.198 6.476 2.640
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
4.110 4.110 4.652 4.652 4.833 4.833 6.820 6.820 7.904 7.904 8.446 8.446 8.987 8.987
17
4.003 4.003 4.538 4.538 4.724 4.724 6.812 6.812 7.790 7.790 8.331 8.331 8.872 8.872
19
3.895 3.895 4.424 4.424 4.615 4.615 6.804 6.804 7.676 7.676 8.216 8.216 8.756 8.756
21 3.787 3.787 4.315 4.315 4.506 4.506 6.706 6.706 7.562 7.562 8.102 8.102 8.641 8.641
23 3.679 3.679 4.210 4.210 4.397 4.397 6.520 6.520 7.448 7.448 7.987 7.987 8.525 8.525
25 3.572 3.572 4.105 4.105 4.288 4.288 6.334 6.334 7.335 7.335 7.872 7.872 8.410 8.410
27
3.464 3.464 4.001 4.001 4.180 4.180 6.147 6.147 7.221 7.221 7.758 7.758 8.294 8.294
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
