ELECTRICAL DATA - HEATPUMP (R22)
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
POWER SOURCE V/Ph/Hz
RATED INPUT POWER W
RATED RUNNING CURRENT A
MOTOR OUTPUT W
POWER SOURCE V/Ph/Hz
RATED INPUT POWER W
RATED RUNNING CURRENT A
MOTOR OUTPUT W
POWER SOURCE V/Ph/Hz
CAPACITOR mF
RATED INPUT POWER (COOLING) W
RATED INPUT POWER (HEATING) W
RATED RUNNING CURRENT (COOLING) A
RATED RUNNING CURRENT (HEATING) A
LOCKED ROTOR AMP. A
ALC 28CR ALC 30CR
POWER SOURCE V/Ph/Hz
RATED INPUT POWER W
RATED RUNNING CURRENT A
MOTOR OUTPUT W
POWER SOURCE V/Ph/Hz
RATED INPUT POWER W 142 220
RATED RUNNING CURRENT A 0.62 1.02
MOTOR OUTPUT W 75 145
68
CLASS E -
POWER SOURCE V/Ph/Hz
CAPACITOR mF 50.0 50.0
RATED INPUT POWER (COOLING) W 2570 2377
RATED INPUT POWER (HEATING) W
2610 2584
RATED RUNNING CURRENT (COOLING) A
12.3 11.5
RATED RUNNING CURRENT (HEATING) A 12.4 12.3
LOCKED ROTOR AMP. A 66 82
MODEL
INDOOR UNIT ACM 25ER
OUTDOOR UNIT ALC 25CR
INDOOR MOTOR
INSULATION GRADE
CLASS B
220 - 240 / 1 / 50
109
0.49
65
POLES
4
OUTDOOR MOTOR
INSULATION GRADE CLASS B
220 - 240 / 1 / 50
132
0.58
64
POLES
6
COMPRESSOR
INSULATION GRADE CLASS E
220 - 240 / 1 / 50
45.0
2222
2062
11.0
10.6
54
MODEL
INDOOR UNIT ACM 28ER
OUTDOOR UNIT
INDOOR MOTOR
INSULATION GRADE
CLASS B
220 - 240 / 1 / 50
150
0.75
70
POLES 4
COMPRESSOR
INSULATION GRADE
220 - 240 / 1 / 50
OUTDOOR MOTOR
INSULATION GRADE
CLASS B
220 - 240 / 1 / 50
POLES
