MODEL : A4MST 151515 AR
1. ASSY., BASE PAN
16. ASSY., CAP. TUBE 1 ( 1.5 HP )
2. ASSY., INS. PARTITION
17. ASSY., CAP. TUBE 2 ( 1.5 HP )
3. ASSY., OUTDOOR COIL MAIN
18. ASSY., CAP. TUBE 3 ( 1.5 HP )
4. CLIP, SENSOR M2 6mm x 9.52mm
19. ASSY., SIDE PANEL RIGHT INS.
5. SENSOR, OUTDOOR DEFROST
20. PANEL, SIDE LEFT
6. ASSY., VALVE PLATE MAIN
21. ASSY., ORIFICE 19” PROPELLER
7. FLARE JOINT VALVE PLATE
22. BRACKET, MOTOR
8. ASSY., 3-WAY VALVE ( 1/2" )
23. ASSY., FAN MOTOR
9. ASSY., 3-WAY VALVE ( 1/2" )
24. PROPELLER, FAN ( 19” )
10. SCREW, TRUSS HEAD PHILLIP
25. ASSY., PANEL TERMINAL BOX
11. ASSY., 2-WAY VALVE ( 1/4” )
12. ASSY., COMP. 4KS2250AA
26. FAN, GUARD
13. ASSY., 4WV COMP. 1 ( 1.5 HP )
27. PANEL, TOP
14. ASSY., 4WV COMP. 2 ( 1.5 HP )
15. ASSY., 4WV COMP. 3 ( 1.5 HP )
28. PANEL, FRONT
83
