MODEL : A4MST 101515 AR
1. ASSY., BASE PAN
16. ASSY., 4WV COMP. 2 ( 1.5 HP )
2. ASSY., INS. PARTITION
18. ASSY., CAP. TUBE 1 ( 1.0 HP )
3. ASSY., OUTDOOR COIL MAIN
19. ASSY., CAP. TUBE 2 ( 1.5 HP )
4. CLIP, SENSOR M2 6mm x 9.52mm
20. ASSY., CAP. TUBE 3 ( 1.5 HP )
5.
21. ASSY., SIDE PANEL RIGHT INS.
6.
SENSOR, OUTDOOR DEFROST
22. ASSY., ORIFICE 19” PROPELLER
7
. ASSY., COMP. 4PS1640AA
23. BRACKET, MOTOR
8
. ASSY., VALVE PLATE MAIN
24. ASSY., FAN MOTOR
9
. FLARE JOINT VALVE PLATE
25. PROPELLER, FAN ( 19” )
10
. ASSY., 3-WAY VALVE ( 1/2" )
26. ASSY., PANEL TERMINAL BOX
11
. ASSY., 3-WAY VALVE ( 1/2" )
27. FAN, GUARD
12
. ASSY., 3-WAY VALVE ( 3/8” )
28. PANEL, FRONT
13
. SCREW, TRUSS HEAD PHILLIP
29. PANEL, TOP
14. ASSY., 2-WAY VALVE ( 1/4” )
17. ASSY., 4WV COMP. 3 ( 1.5 HP )
. ASSY., COMP. 4KS2250AA
15. ASSY., 4WV COMP. 1 ( 1.0 HP )
82
