MODEL : A4MST 101015 AR
1. ASSY., BASE PAN
16. ASSY., 4WV COMP. 2 ( 1.0 HP )
2. COMPRESSOR, RUBBER GROMMET
18. ASSY., CAP. TUBE 1 ( 1.0 HP )
3. ASSY., INS. PARTITION
19. ASSY., CAP. TUBE 2 ( 1.0 HP )
4. ASSY., OUTDOOR COIL MAIN
20. ASSY., CAP. TUBE 3 ( 1.5 HP )
5. CLIP, SENSOR M2 6mm x 9.52mm
21. ASSY., SIDE PANEL RIGHT INS.
6. SENSOR, OUTDOOR DEFROST
22. PANEL, SIDE LEFT
7. ASSY., COMP. 4PS1640AA
23. ASSY., ORIFICE 19” PROPELLER
8
. ASSY., VALVE PLATE MAIN
24. BRACKET, MOTOR
9
. FLARE JOINT VALVE PLATE
25. ASSY., FAN MOTOR
10
. ASSY., 3-WAY VALVE ( 1/2" )
26. PROPELLER, FAN ( 19” )
11
. ASSY., 3-WAY VALVE ( 3/8” )
27. ASSY., PANEL TERMINAL BOX
12
. SCREW, TRUSS HEAD PHILLIP
28. FAN, GUARD
13
. ASSY., 2-WAY VALVE ( 1/4” )
29. PANEL, FRONT
14
15. ASSY., 4WV COMP. 1 ( 1.0 HP )
30. PANEL, TOP
17. ASSY., 4WV COMP. 3 ( 1.5 HP )
. ASSY., COMP. 4KS2250AA
81
