MODEL : A4MST 101010 AR
1. ASSY., BASE PAN 16. ASSY., 4WV COMP. 3 ( 1.0 HP )
2. COMPRESSOR, RUBBER GROMMET 17. ASSY., CAP. TUBE 1 ( 1.0 HP )
3. ASSY., INS. PARTITION 18. ASSY., CAP. TUBE 2 ( 1.0 HP )
4. ASSY., OUTDOOR COIL MAIN 19. ASSY., CAP. TUBE 3 ( 1.0 HP )
5. CLIP, SENSOR M2 6mm x 9.52mm 20. ASSY., SIDE PANEL RIGHT INS.
6. SENSOR, OUTDOOR DEFROST 21. PANEL, SIDE LEFT
7. ASSY., COMP. 4PS1640AA 22. ASSY., ORIFICE 19” PROPELLER
8. ASSY., VALVE PLATE MAIN 23. BRACKET, MOTOR
9. FLARE JOINT VALVE PLATE 24. ASSY., FAN MOTOR
10. ASSY., 3-WAY VALVE ( 1/2" ) 25. PROPELLER, FAN ( 19” )
11. ASSY., 3-WAY VALVE ( 3/8” ) 26. ASSY., PANEL TERMINAL BOX
12. SCREW, TRUSS HEAD PHILLIP 27. FAN, GUARD
13. ASSY., 2-WAY VALVE ( 1/4” ) 28. PANEL, TOP
14. ASSY., 4WV COMP. 1 ( 1.0 HP )
15. ASSY., 4WV COMP. 2 ( 1.0 HP )
29. PANEL, FRONT
80
