MODEL : AMST 101025 / 101525 / 151525 A
1. ASSY, PANEL BASE
16. ASSY, FRONT PANEL
2. ASSY, MAIN COIL
17. ASSY, CONTROL BOX
3. BRACKET, MOTOR
18. ASSY, STICKER GUIDE TER. BOX COVER
4. FAN MOTOR (YJ145 - SWELLING)
19. ASSY, PANEL SERVICE
5. FAN, BLADE
20. PANEL, SIDE LEFT
6. ASSY, MOUNT PLATE BTM
21. PANEL, TOP
7. RUBBER, GROMMET
22. BUSH, RUBBER
8. COMPRESSOR, (2PS164D2BC02)
23. ASSY, UNIT TUBING
9. COMPRESSOR, (2KS2240D3AC02)
24. SCREW, SELF TAPPING
10. ASSY, VALVE BRACKET
25. SCREW, PH T/HD 8 x 3/8 - (R / P)
11. ASSY, PANEL PARTITION
26. SCREW, TRUSS HEAD PHILIP M5 x 16
12. ASSY, MOUNTING PLT TOP
27. WASHER, SPRING OD15 x ID8.5 x t1.2
13. ASSY, PANEL BACK RIGHT
14. ASSY, COMP. 2JS438D3 (BENDED)
15. ASSY, VALVE BRACKET
79
