MODEL : AMSH 8K66 / 66K66 / 66K555 A
1. ASSY, BACK PANEL 14. FAN BLADE
2. ASSY, TOP PANEL 15. WASHER, RING
3. ASSY, CONDENSER COIL 16. MOTOR, FAN
4. NUT M8, WITH WASHER 17. BRACKER, FAN MOTOR
5. ROTARY COMPRESSOR A (2PS192D2AB02) 18. ASSY, BASE PAN
6. ROTARY COMPRESSOR B (2PS192D2AB02) 19. ASSY, PARTITION
7. GROMMET, RUBBER 20. ASSY, TERMINAL BOX PANEL
8. SCREW, TRUSS HEAD PHILIP 21. ASSY, SIDE PANEL
9. WASHER, SPRING 22. ASSY, ACCESS PANEL
10. ASSY, MOUNTING PLATE 23. ASSY, VALVE PLATE
11. ASSY, PANEL FRONT 24. DAMPER, RUBBER
12. NUT, HEXAGON 3/8" 25. HANDLING HANDLE
13. WASHER, SQUARE
85
