Acson AWM 25G Technical Manual

131
Exploded View and Part List AWM-G-2009
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
INDOOR UNIT
MODEL: AWM/A5WM 07/09/10/15GR
No Description Part Number
1 Assy. Chassis
AWM/A5WM 07/09GR R50124064147
AWM/A5WM 10/15GR R50124064151
2 Fan Motor
AWM/A5WM 07/09GR R03034064425
AWM/A5WM 10GR R03034071487
AWM/A5WM 15GR R03034064426
3 Cross Flow Fan
AWM/A5WM 07/09GR R03029019462
AWM/A5WM 10/15GR R03029019461
4 Fan Bush R11014029514
5 Assy. Indoor Coil
AWM/A5WM 07/09GR R50024063765
AWM/A5WM 10GR R50024064225
AWM/A5WM 15GR R50024066054
6 Piping Clamp R12014060544
7 Assy. Drain Pan
AWM/A5WM 07/09GR R50124064148
AWM/A5WM 10/15GR R50124064152
8 Drain Hose R10024018204
9 Assy. Control Box R50044085737
10 Assy. Control Box Cover R50124074570
11 Control Module R04084067263
12 Assy. Air Discharge Housing
AWM/A5WM 07/09GR R50124085606
AWM/A5WM 10/15GR R50124085608
No Description Part Number
13 Top Louver
AWM/A5WM 07/09GR R12014085590
AWM/A5WM 10/15GR R12014085592
14 Bottom Louver
AWM/A5WM 07/09GR R12014085591
AWM/A5WM 10/15GR R12014085593
15 Filter
AWM/A5WM 07/09GR R12014062320
AWM/A5WM 10/15GR R12014062321
16 Nanosilver Filter
AWM/A5WM 07/09GR R12014084996
AWM/A5WM 10/15GR R12014080141
Nanovis Filter
AWM/A5WM 07/09GR R12014084997
AWM/A5WM 10/15GR R12014080143
17 Ionizer R04239019730
18 Handset, Wireless G18 R04084100952
19 Air Swing Motor R03039021375
20 Assy. Mounting Plate
AWM/A5WM 07/09GR R50014061333
AWM/A5WM 10/15GR R50014062324
21 Assy. Front Cover
AWM/A5WM 07/09GR R50124084806
AWM/A5WM 10/15GR R50124084807
Parts Not In Diagram
Service Panel R12014060547
