Acson AWM 25G Technical Manual

35
Engineering & Physical Data AWM-G-2009
Engineering & Physical Data
General Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 07G AWM 09G
OUTDOOR UNIT ALC 07C ALC 09C
NOMINAL CAPACITY
Btu/h 7000 9000
W 2050 2640
NOMINAL TOTAL INPUT POWER W 590 919
NOMINAL RUNNING CURRENT A 2.70 4.10
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
EER W/W 3.47 2.87
REFRIGERANT TYPE R22 R22
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE
INDOOR UNIT
CONTROL
AIR DISCHARGE
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
DOUBLE LOUVER (UP & DOWN) &
GRILLE (LEFT & RIGHT)
OPERATION LCD REMOTE CONTROL LCD REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 118 / 250 130 / 275
MEDIUM l/s / CFM 104 / 220 106 / 225
LOW l/s / CFM 85 / 180 83 / 175
SOUND PRESSURE LEVEL (H/M/L) dBA 38 / 33 / 28 40 / 35 / 29
UNIT DIMENSION
HEIGHT mm/in 260 / 10.2 260 / 10.2
WIDTH mm/in 799 / 31.5 799 / 31.5
DEPTH mm/in 198 / 7.8 198 / 7.8
PACKING DIMENSION
HEIGHT mm/in 337 / 13.3 337 / 13.3
WIDTH mm/in 857 / 33.7 857 / 33.7
DEPTH mm/in 270 / 10.6 270 / 10.6
UNIT WEIGHT kg/lb 8.5 / 18.7 10 / 22.1
CONDENSATE DRAIN SIZE mm/in 16 / 0.6 16 / 0.6
OUTDOOR UNIT
AIR FLOW l/s / CFM 321 / 680 307 / 650
SOUND PRESSURE LEVEL dBA 45 46
UNIT DIMENSION
HEIGHT mm/in 495 / 19.5 495 / 19.5
WIDTH mm/in 600 / 23.6 600 / 23.6
DEPTH mm/in 245 / 9.7 245 / 9.7
PACKING DIMENSION
HEIGHT mm/in 575 / 22.6 575 / 22.6
WIDTH mm/in 715 / 28.1 715 / 28.1
DEPTH mm/in 330 / 13.0 330 / 13.0
UNIT WEIGHT kg/lb 28 / 61.7 28 / 61.7
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 / 1/4 6.35 / 1/4
GAS mm/in 9.52 / 3/8 9.52 / 3/8
REFRIGERANT CHARGE kg/lb 0.50 / 1.10 0.53/ 1.16
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
