Acson AWM 25G Technical Manual

66
AWM-G-2009 Engineering & Physical Data
Component Data - Heat Pump (R410A)
MODEL
INDOOR UNIT A5WM 301R
OUTDOOR UNIT A5LC - 28CR
INDOOR FAN
TYPE ANTI FUNGUS CROSS FLOW FAN
QUANTITY 1
MATERIAL ACRYLO NITRILE STYRENE
DRIVE DIRECT
DIAMETER mm/in 106 / 4.17
LENGTH mm/in 950 / 37.4
INDOOR FAN MOTOR
TYPE INDUCTION
QUANTITY 1
INDEX OF PROTECTION (IP) IP24
OUTDOOR FAN
TYPE PROPELLER
QUANTITY 1
MATERIAL
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE DIRECT
DIAMETER mm/in 457.2/18
OUTDOOR FAN
MOTOR
TYPE INDUCTION
QUANTITY 1
INDEX OF PROTECTION (IP) IP54
COMPRESSOR
TYPE ROTARY HERMETIC
OIL TYPE RB68A OR FREOL ALPHA68M
OIL AMOUNT cm
3
/ fl .oz. 1130 / 39.7
INDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276
THICKNESS mm/in 0.28 / 0.011
FIN
MATERIAL
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
THICKNESS mm/in 0.11 / 0.0043
FACE AREA m
2
/ft
2
0.30 / 3.23
ROW 2
FIN PER INCH 18
OUTDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276
THICKNESS mm/in 0.28 / 0.011
FIN
MATERIAL ALUMINIUM (CORR. FIN)
THICKNESS mm/in 0.11 / 0.004
FACE AREA m
2
/ft
2
0.62 / 6.63
ROW 2
FIN PER INCH 18
AIR QUALITY
FILTER
TYPE SARANET + IONIZER
QUANTITY pc 3 X 3
SIZE
LENGTH mm/in 330 / 13.0
WIDTH mm/in 317 / 12.4
THICKNESS mm/in 1.8 / 0.07
NEGATIVE IONIZER NO
CASING
INDOOR UNIT
MATERIAL HIGH IMPACT POLYSTYRENE
COLOUR IVORY
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL
COLOUR LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
