Acson AWM 25G Technical Manual

92
AWM-G-2009 Performance Data
Heat Pump (R410A)
Model: A5WM 20GR - A5LC 20CR (3 PHASE)
Cooling Mode
ID
DB°C
ID
WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
20
15 5.206 3.550 4.976 3.280 4.711 3.049 4.447 2.818 4.182 2.587 3.864 2.310
16 5.402 3.346 5.156 3.114 4.892 2.902 4.628 2.689 4.365 2.477 4.049 2.222
24
16 5.402 4.235 5.156 4.003 4.892 3.791 4.628 3.579 4.365 3.366 4.049 3.112
17 5.597 4.031 5.335 3.838 5.073 3.644 4.810 3.450 4.548 3.256 4.233 3.024
18 5.809 3.810 5.541 3.642 5.274 3.474 5.006 3.306 4.739 3.138 4.417 2.936
19 6.025 3.571 5.775 3.345 5.526 3.120 5.276 2.894 4.970 2.873 4.602 2.848
20 6.229 3.353 5.935 3.175 5.640 2.997 5.346 2.819 5.052 2.641 4.699 2.482
28
18 5.809 4.699 5.541 4.531 5.274 4.363 5.006 4.195 4.739 4.027 4.417 3.825
19 6.025 4.460 5.775 4.235 5.526 4.009 5.276 3.783 4.970 3.762 4.602 3.737
20 6.229 4.243 5.935 4.065 5.640 3.887 5.346 3.709 5.052 3.531 4.699 3.317
21 6.437 4.008 6.121 3.795 5.806 3.581 5.490 3.367 5.174 3.153 4.795 2.897
22 6.646 3.774 6.308 3.525 5.971 3.275 5.634 3.025 5.297 2.776 4.892 2.476
23 6.854 3.540 6.495 3.255 6.136 2.696 5.778 2.684 5.419 2.398 4.988 2.056
24 7.062 3.306 6.682 2.985 6.302 2.663 5.922 2.342 5.541 2.021 5.085 1.635
30
20 6.229 4.687 5.935 4.509 5.640 4.331 5.346 4.153 5.052 3.975 4.699 3.762
21 6.437 4.453 6.121 4.239 5.806 4.025 5.490 3.812 5.174 3.598 4.795 3.341
22 6.646 4.219 6.308 3.969 5.971 3.720 5.634 3.470 5.297 3.220 4.892 2.921
23 6.854 3.985 6.495 3.699 6.136 3.414 5.778 3.128 5.419 2.843 4.988 2.500
24 7.062 3.750 6.682 3.429 6.302 3.108 5.922 2.787 5.541 2.465 5.085 2.080
Model: A5WM 20GR - A5LC 20CR (3 PHASE)
Heating Mode
ID WB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 3.278 3.278 3.710 3.710 3.854 3.854 5.438 5.438 6.302 6.302 6.735 6.735 7.167 7.167
17 3.192 3.192 3.598 3.598 3.776 3.776 5.432 5.432 6.259 6.259 6.697 6.697 7.135 7.135
19 3.1069 3.106 3.485 3.485 3.698 3.698 5.425 5.425 6.215 6.215 6.659 6.659 7.103 7.103
21 3.020 3.020 3.401 3.401 3.620 3.620 5.376 5.376 6.171 6.171 6.621 6.621 7.071 7.071
23 2.934 2.934 3.344 3.344 3.542 3.542 5.285 5.285 6.127 6.127 6.583 6.583 7.039 7.039
25 2.848 2.848 3.287 3.287 3.464 3.464 5.194 5.194 6.083 6.083 6.545 6.545 7.007 7.007
27 2.762 2.762 3.230 3.230 3.386 3.386 5.103 5.103 6.039 6.039 6.507 6.507 6.975 6.975
FROST REGION
