Acson awm07f User Manual

147
Model: ALC 18CR / 20CR
No Descriptions Part No No Descriptions Part No
1 ASSY,PAN BASE (5SL20C/CR) R50014078281 13 PANEL TOP (SL20C/25C/28C/CR) R01014070596
2 ASSY,OUTDOOR COIL 7mm coil
ALC 18CR R50024090296
ALC 20CR R50024075143
3 BRACKET MOTOR (SL20C/CR) R01014070601
16 ASSY VALVE COVER (SL20C/CR) R50124072885
ASSY. CAP TUBE DIET COMP
ALC 18CR R50024089931
ALC 20CR R50024087058
18 PARTITION (SL20C/CR) R01014070603
7 PANEL RIGHT BACK (SL20C/CR) R01014070599
9 PANEL FRONT/LEFT (SL20C/CR) R01014070597
10 PANEL SERVICE (SL20C/CR) R01014070598
ASSY FLARE VALVE 3
WAY(5/8")SL20C/25C/28
R50054072863
ASSY,VALVE 2 WAY(1/4")JA28493-
1MA HANGJI
R50059022156
CAPACITOR, CMPSR 60uF/450V
Shizuki
R04029026782
BACK GRILLE WITH PAINT
(SL18C/20C/CR)
R50019026515
14
ASSY FRONT GRILLE
(SL20C/25C/28C/CR)
R50124072880
15
PLASTIC,HANDLE
SL07C/09C/10C/15C/CR
R12014057948
11
PANEL TERMINAL COVER
(SL20C/25C/28C/CR)
R01014070838
12
ASSY. CONTROL PANEL
(SL20CR/25CR)
R50044086143
6 R50014072861
8
COMPRESSOR, 2KS324D5AA04
Matsushita
R04019027266
4 R03039024539
FAN PROPELLER, ¥460 0Z40700
SUNWILL CHINA
5 R03019023393
Parts not showed in diagram
MOTOR, YDK64-6C/MSL25C-501-
WL
ASSY VALVE BRACKET
(SL20C/CR)-R22
17
