153
MODEL: A5LC 07CR
No Descriptions Part No No Descriptions Part No
1 Assy., Base Pan R50014057372 12 Right Panel R01014052509
2 Assy., Condenser Coil R50024064720 13 Assy. Control Panel R50044059032
3 Valve Bracket R01014051164 14 Assy., Front Panel R01014052512
4 Compressor R04019019592 15 Assy., Valve Cover R50124055172
5 Assy., Partition R50064065275 16 Assy., Front Grille R50124056905
6 Assy., 4 Way Vlave R50024066259 17 Plastic, Handle R12014057948
7 Assy., Cap Tube R50024066452 18 Rubber Grommet R11059011558
8 Bracket, Fan Motor R01014052516 19 Assy., Flare Valve 2 Ways 1/4" R50059019453
9 Fan Motor R03039015324 20 Assy., Flare Valve 3 Ways 3/8" R50059019454
10 Fan Blade R03019004131 21 Sensor, Outdoor Defrost R50134039416
11 Left Panel R01014052510
