Acson awm10f User Manual

R22 MODELS
(HEATPUMP)
MODEL : AWM 20FR / ALC 20BR
COOLING MODE
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15
5.685 3.279 5.363 3.031 5.042 2.784 4.720 2.536 4.272 2.126 3.962 1.842 3.812 1.705 3.708 1.609
16
6.068 3.097 5.683 2.853 5.298 2.609 4.913 2.365 4.447 1.971 4.124 1.698 3.968 1.567 3.859 1.475
16
6.068 4.162 5.683 3.918 5.298 3.674 4.913 3.430 4.447 3.036 4.124 2.763 3.968 2.632 3.859 2.540
17
6.451 3.979 6.003 3.739 5.554 3.499 5.106 3.258 4.621 2.881 4.286 2.620 4.124 2.493 4.011 2.405
18
6.835 3.797 6.323 3.560 5.811 3.324 5.299 3.087 4.796 2.726 4.448 2.476 4.280 2.355 4.162 2.271
19
7.218 3.614 6.642 3.382 6.067 3.149 5.491 2.916 4.970 2.571 4.610 2.332 4.435 2.217 4.314 2.136
20
7.604 3.432 6.988 3.206 6.372 2.979 5.757 2.753 5.210 2.423 4.833 2.195 4.650 2.085 4.522 2.008
18
6.835 4.862 6.323 4.625 5.811 4.389 5.299 4.152 4.796 3.791 4.448 3.541 4.280 3.420 4.162 3.336
19
7.218 4.679 6.642 4.447 6.067 4.214 5.491 3.981 4.970 3.636 4.610 3.397 4.435 3.282 4.314 3.201
20
7.604 4.497 6.988 4.271 6.372 4.044 5.757 3.818 5.210 3.488 4.833 3.260 4.650 3.150 4.522 3.073
21
7.992 4.315 7.351 4.097 6.711 3.878 6.071 3.660 5.494 3.345 5.096 3.128 4.903 3.022 4.769 2.949
22
8.379 4.133 7.714 3.923 7.049 3.712 6.384 3.502 5.778 3.202 5.359 2.995 5.157 2.895 5.015 2.825
23
8.767 3.951 8.078 3.749 7.388 3.546 6.698 3.344 6.062 3.059 5.623 2.862 5.410 2.767 5.262 2.701
24
9.155 3.770 8.441 3.575 7.726 3.380 7.012 3.185 6.346 2.916 5.886 2.730 5.663 2.639 5.508 2.576
20
7.604 5.030 6.988 4.803 6.372 4.577 5.757 4.350 5.210 4.021 4.833 3.793 4.650 3.683 4.522 3.606
21
7.992 4.848 7.351 4.629 6.711 4.411 6.071 4.192 5.494 3.878 5.096 3.660 4.903 3.555 4.769 3.481
22
8.379 4.666 7.714 4.455 7.049 4.245 6.384 4.034 5.778 3.735 5.359 3.527 5.157 3.427 5.015 3.357
23
8.767 4.484 8.078 4.281 7.388 4.079 6.698 3.876 6.062 3.591 5.623 3.395 5.410 3.300 5.262 3.233
24
9.155 4.302 8.441 4.107 7.726 3.913 7.012 3.718 6.346 3.448 5.886 3.262 5.663 3.172 5.508 3.109
40 46 5020 25 30 35
HIGH AMBIENT
30
54
20
24
28
ID DB°C ID WB°C
Outdoor DB°C
HEATING MDOE
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 3.686 3.686 4.112 4.112 4.254 4.254 5.816 5.816 6.668 6.668 7.094 7.094 7.520 7.520
17 3.651 3.651 4.075 4.075 4.216 4.216 5.832 5.832 6.609 6.609 7.031 7.031 7.453 7.453
19
3.616 3.616 4.038 4.038 4.178 4.178 5.847 5.847 6.550 6.550 6.968 6.968 7.386 7.386
21 3.581 3.581 4.000 4.000 4.140 4.140 5.862 5.862 6.490 6.490 6.905 6.905 7.319 7.319
23 3.550 3.550 3.964 3.964 4.102 4.102 5.739 5.739 6.431 6.431 6.841 6.841 7.252 7.252
25
3.519 3.519 3.928 3.928 4.064 4.064 5.617 5.617 6.371 6.371 6.778 6.778 7.185 7.185
27 3.488 3.488 3.891 3.891 4.026 4.026 5.494 5.494 6.312 6.312 6.715 6.715 7.118 7.118
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
20
