R407C MODELS
(HEATPUMP)
MODEL : AWM 20FR / A4LC 20BR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 5.236 2.879 4.940 2.651 4.644 2.423 4.347 2.195 4.051 1.966 3.696 1.693
16
5.589 2.711 5.234 2.487 4.880 2.262 4.525 2.037 4.170 1.812 3.745 1.543
16
5.589 3.776 5.234 3.552 4.880 3.327 4.525 3.102 4.170 2.877 3.745 2.608
17
5.942 3.608 5.529 3.387 5.116 3.166 4.703 2.944 4.289 2.723 3.794 2.458
18
6.295 3.440 5.823 3.222 5.352 3.005 4.880 2.787 4.409 2.569 3.843 2.307
19 6.648 3.272 6.118 3.058 5.588 2.843 5.058 2.629 4.528 2.415 3.892 2.157
20
7.003 3.105 6.436 2.896 5.869 2.687 5.302 2.479 4.735 2.270 4.055 2.020
18
6.295 4.505 5.823 4.287 5.352 4.070 4.880 3.852 4.409 3.634 3.843 3.372
19 6.648 4.337 6.118 4.123 5.588 3.908 5.058 3.694 4.528 3.480 3.892 3.222
20
7.003 4.170 6.436 3.961 5.869 3.752 5.302 3.544 4.735 3.335 4.055 3.085
21 7.361 4.002 6.771 3.801 6.181 3.599 5.591 3.398 5.002 3.197 4.294 2.955
22
7.718 3.834 7.105 3.640 6.493 3.446 5.880 3.252 5.268 3.058 4.533 2.826
23
8.075 3.667 7.440 3.480 6.805 3.294 6.169 3.107 5.534 2.920 4.772 2.696
24 8.432 3.499 7.774 3.320 7.116 3.141 6.458 2.961 5.801 2.782 5.011 2.567
20
7.003 4.702 6.436 4.493 5.869 4.285 5.302 4.076 4.735 3.868 4.055 3.617
21
7.361 4.534 6.771 4.333 6.181 4.132 5.591 3.931 5.002 3.729 4.294 3.488
22
7.718 4.367 7.105 4.173 6.493 3.979 5.880 3.785 5.268 3.591 4.533 3.358
23
8.075 4.199 7.440 4.013 6.805 3.826 6.169 3.639 5.534 3.453 4.772 3.229
24 8.432 4.032 7.774 3.852 7.116 3.673 6.458 3.494 5.801 3.314 5.011 3.099
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
HEATING MODE
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
TC
(
kW
)
SC
(
kW
)
15 3.502 3.502 3.907 3.907 4.042 4.042 5.526 5.526 6.335 6.335 6.740 6.740 7.144 7.144
17 3.469 3.469 3.871 3.871 4.005 4.005 5.540 5.540 6.279 6.279 6.680 6.680 7.081 7.081
19
3.436 3.436 3.836 3.836 3.969 3.969 5.554 5.554 6.222 6.222 6.620 6.620 7.017 7.017
21
3.402 3.402 3.800 3.800 3.933 3.933 5.569 5.569 6.166 6.166 6.559 6.559 6.953 6.953
23
3.373 3.373 3.766 3.766 3.897 3.897 5.452 5.452 6.109 6.109 6.499 6.499 6.890 6.890
25 3.343 3.343 3.731 3.731 3.861 3.861 5.336 5.336 6.052 6.052 6.439 6.439 6.826 6.826
27 3.314 3.314 3.697 3.697 3.824 3.824 5.219 5.219 5.996 5.996 6.379 6.379 6.762 6.762
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
