Acson awm10f User Manual

MODEL : AWM 20F / 20FR / 25F / 25FR / 301/ 301R
1. ASSY. CHASIS 8. ASSY. EVAPORATOR COIL
2. PIPING, CLAMP 9. ASSY. AIR DISCHARGE HOUSING
3. ASSY. CONTROL BOX 10. CROSS FLOW FAN
4. ASSY. CONTROL BOX COVER 11. SCREW, SELF TAPPING ROUND HEAD
5. ASSY. MOUNTING PLATE 12. SCREW, SELF TAPPING PAN HEAD
6. ASSY. FAN MOTOR 13. WASHER, INT. TEETH STAR
7. ASSY. FRONT COVER 14. SCREW, PAN HEAD MACHINED
96

Acson awm10f Specifications

General

Brand	Acson
Model	awm10f
Category	Air Conditioner
Language	English
