Performance Data AWM-J-2010
3
rd
Step:
To obtain the Total capacity and Sensible capacity for
(a) Indoor Condition: 25°C DB, 17°C WB
Outdoor Condition: 37°C DB
Indoor
DB˚C
Indoor
WB˚C
Outdoor DB, ˚C
35 37 40
TC
(kW)
SHC
(kW)
PI
(kW)
TC
(kW)
SHC
(kW)
PI
(kW)
TC
(kW)
SHC
(kW)
PI
(kW)
23 15
......................
11.16 10.05 4.03 x y z 10.79 9.92 4.39
Total capacity, TC
Interpolation Method:
⇒
37º C – 35º C
=
x – 11.16kW
40º C – 35º C 10.79kW – 11.16kW
⇒ x = 11.01kW
Sensible capacity, SHC
Interpolation Method:
⇒
37º C – 35º C
=
y – 10.05kW
40º C – 35º C 9.92kW – 10.05kW
⇒ y = 9.99kW
Power Input, PI
Interpolation Method:
⇒
37º C – 35º C
=
z – 4.03kW
40º C – 35º C 4.39kW – 4.03kW
⇒ z = 4.17kW
