AWM-J-2010 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
INDOOR UNIT
MODEL: AWM09/15J/JR, A5WM10/15J/JR
No Description
1 Assy. Front Grille
2 Panel, Acson
3
Disch. Grille Hor.Blade Assy.
4 Assy. Bottom Frame
5 Assy. Control Box
6 Assy. Service Cover
7 Assy. Piping Fixture
8 Motor
9 Motor Mounting Plate (1)
10 Motor Mounting Plate (2)
11 Blower
12 Assy. Installation Plate
No Description
13 Right Side Panel
14 Cover, Drip Proof
15 Clip, Coil Sensor
16 Assy. Heat Exchanger
17 Assy. Drain Hose
18 Fan Bearing Vibration Absorber
19 Air Filter
20 Bio Antibody Filter (Pack)
Titanium Apatite Filter (Pack)
21 Handset, Wireless G18
22 Control Module
To Next Page
