A5LCY-E-2010 Engineering & Physical Data
MODEL
OUTDOOR UNIT A5LCY - 10ER A5LCY - 15ER
INDOOR UNIT A5WMY - 10KR A5WMY - 15KR
OUTDOOR UNIT
AIR FLOW (COOLING) CFM 1017 921
AIR FLOW (HEATING) CFM 1017 921
SOUND PRESSURE LEVEL (COOLING) dBA 46 48
SOUND PRESSURE LEVEL (HEATING) dBA 47 48
UNIT DIMENSION
HEIGHT mm/in 550 550
WIDTH mm/in 658 658
DEPTH mm/in 275 275
PACKING DIMENSION
HEIGHT mm/in 592 592
WIDTH mm/in 771 771
DEPTH mm/in 348 348
UNIT WEIGHT kg/lb 28 30
PIPE CONNECTION
TYPE FLARE VALVE FLARE VALVE
SIZE
LIQUID mm/in 6.35 6.35
GAS mm/in 9.52 9.52
REFRIGERANT CHARGE kg/lb 0.74 1
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151..
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1m IN FRONT AND 1m
BELOW THE UNIT.
