Acson E Series - Electrical Data

26
A5LCY-E-2010 Electrical Data
Electrical Data
MODEL
OUTDOOR UNIT A5LCY - 10ER A5LCY - 15ER
INDOOR UNIT A5WMY - 10KR A5WMY - 15KR
INDOOR MOTOR
INSULATION GRADE EE
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 34 42
RATED RUNNING CURRENT A 0.19 0.21
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE EE
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
RATED INPUT POWER W 66 67
RATED RUNNING CURRENT A 0.31 0.31
MOTOR OUTPUT W 26 26
POLES 66
COMPRESSOR
INSULATION GRADE EE
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50
CAPACITOR mF --
RATED INPUT POWER (COOLING) W 660 941
RATED INPUT POWER (HEATING) W 728 941
RATED RUNNING CURRENT (COOLING) A 3.60 4.48
RATED RUNNING CURRENT (HEATING) A 3.50 4.38
LOCKED ROTOR AMP. A --
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
0.18
0.18
3.22
4.32
3.52
4.12
