Acson E Series - Components Data - Heat Pump

23
Engineering & Physical Data A5LCY-E-2010
Components Data - Heat pump
MODEL
OUTDOOR UNIT A5LCY - 10ER A5LCY - 15ER
INDOOR UNIT A5WMY - 10KR A5WMY - 15KR
INDOOR FAN
TYPE CROSS FLOW FAN CROSS FLOW FAN
QUANTITY 11
MATERIAL ASG30% ASG30%
DRIVE DIRECT DIRECT
DIAMETER mm/in 92 92
LENGTH mm/in 626 626
INDOOR FAN MOTOR
TYPE MM6CO2J2VA MM6CO2J2VA
QUANTITY 11
INDEX OF PROTECTION (IP) IP20 IP20
OUTDOOR FAN
TYPE PROPELLER PROPELLER
QUANTITY 11
MATERIAL ASG20% ASG20%
DRIVE DIRECT DIRECT
DIAMETER mm/in 370 370
OUTDOOR FAN MO-
TOR
TYPE ARS6402DC ARS6402DC
QUANTITY 11
INDEX OF PROTECTION (IP) IP23 IP23
COMPRESSOR
TYPE ROTARY SWING ROTARY SWING
OIL TYPE FVC50K FVC50K
OIL AMOUNT cm3 / fl .oz. 375 375
INDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 77
THICKNESS mm/in 0.28 0.28
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN) ALUMINIUM (HYDROPHILIC FIN)
THICKNESS mm/in 0.1 0.1
FACE AREA m2/ft2 0.179 0.179
ROW 22
FIN PER INCH 24 24
OUTDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 77
THICKNESS mm/in 0.28 0.28
FIN
MATERIAL ALUMINIUM (CORR.) ALUMINIUM (CORR.)
THICKNESS mm/in 0.1 0.1
FACE AREA m2/ft2 0.354 0.35
ROW 12
FIN PER INCH 24 24
AIR QUALITY FILTER
TYPE MILDEW PROOF PP FILTER MILDEW PROOF PP FILTER
QUANTITY pc 22
CASING
INDOOR UNIT
MATERIAL HIPS HIPS
FINISHING MAT MAT
COLOUR WHITE WHITE
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL GALVANISED MILD STEEL
FINISHING POWDER CORTING POWDER CORTING
COLOUR IVORY WHITE IVORY WHITE
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
