A5LCY-E-2010 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
Outdoor Unit
Model: A5LCY 10/15ER
No Description
A1-A10 Assy. Compressor
B1 Assy. Heat Exchanger
B2 Assy. 4WV
B3 Assy. EXV
B7-B12 Flare nut & valve cap
B13, E19 Thermistor Holder
C1-2 Assy. Propeller Fan
C3 Coil guard
C4 Front Grille
E1-B24 Assy. Control Box
E11 EXV Solenoid Coil
E13 Assy. 4WV Coil
No Description
E20 Motor
E23 Reactor
F1 Assy. Botttom Frame
F2 Right Side Plate
F3 Left Side Plate
F4 Front Panel
F5 Assy. Panel Partition
F6 Assy. Fan Motor
F7 Assy. Stop Valve Cover
F10 Top Plate
F11 Stop Valve Mounting Plate
K3 Drain Joint
To Next Page
