42
A5LCY-E-2010 Exploded View and Part List
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
Indoor Unit
Model: A5WMY 10/15KR
No
Description
B1-B3 Assy. Heat Exchanger
B4 Clip, Coil Sensor
C1 Blower
E1-E14 Assy. Control Box
E3 Assy. Control Module
E10 Stepping Motor
E13 Motor
F1 Assy. Bottom Frame
F1-6 Assy. Fan Bearing
F1-11 Assy. Drain Hose
No
Description
F2 Right Side Panel
F3 Left Side Panel
F4 Assy. Front Grille
F6 Assy. Piping Fixture
F7 Assy. Service Cover
F11 Assy. Disch. Grille Horizontal Blade
K2-K5 Assy. Handset, Wireless
K7 Air Filter
K8 Assy. Installation Plate
To Next Page
